Jet FA-3S - 3 Ton 15' Lift 575V 3Ph Electric Chain Hoist Heavy Duty
Jet FA-3S - 3 Ton 15&

Jet FA-3S - 3 Ton 15' Lift 575V 3Ph Electric Chain Hoist Heavy Duty

Jet SKU: FM HST 107265
/

Sold in multiples of 1 (s)

Shipping calculated at checkout.


Usually ships in 5 days

  • Secure payments

3 Ton 15' Lift 575V 3PH Electric Chain Hoist - Heavy Duty

  • Available in single phase or three phase models and various voltages (specify when ordering)
  • 1/2 ton - 5 ton capacities
  • Chain is heat treated, case hardened low wear chain surpassing ISO Class T
  • All models complete with chain collector bucket
  • Reliable electro-magnetic DC brake engages automatically when power is cut off
  • Two button pendant control automatically returns to OFF mode when either button is released
  • 24 volt pendant control for operator safety in damp or humid conditions
  • Strain relief cable protects electrical connections
  • Top and bottom safety hooks designed to bend slowly to warn of overloads
  • Upper and lower limit switches protect hoist from damage if load or chain stop contacts body
  • Gear train and electrical components completely sealed for use outdoors (cover recommended)
  • Modular construction of motor, gear train, and brake assembly allows for quick and easy maintenance
  • Single phase hoists equipped with automatic overload protection preset to 110% of rated capacity
  • Three phase hoists feature reverse phase protection
  • Meets ASME B30.16, CSA, and OSHA standards

    • Product Information

    Brand Jet
    Part # 107265
    Product Type Chain Hoists

    Product Information

  • Rated Lifting Capacity : 6,600 lb
  • Standard Lift : 15'
  • Standard Chain Bucket : #4
  • Hoisting Speed : 8 FPM
  • Voltage : 575 V
  • Power Source : 3 ph
  • Head Room : 31.89 Inch
  • Motor Power : 2.1 HP
  • Duty Rating : 30 min
  • Power Cable Length : 16'
  • Number of Falls : 3
  • Amperes : 2.6
  • A: 5.83 Inch
  • B: 8.19 Inch
  • C: 9.41 Inch
  • D: 16.81 Inch
  • H: 31.89 Inch
  • K: 2.36 Inch
  • L: 2.36 Inch
  • M: 6.50 Inch
  • N: 1.93 Inch
  • O: 1.38 Inch
